SWDH115S
Hole diameter: 89-127mm
Rod: T51
Technical Parameters
-
Main parametersHole diameter
89-127 mm
RodT51
Tube length3660 mm
Maximum hole depth24 m
Dust collectorDry dust removal
-
Hydraulic rock drillModel
HC160Q
Impact power21 kW
Slewing torque1612 Nm
Slewing speed0-130 rpm
-
Air compressorWorking pressure
10 bar
FAD12.8 m³/min
-
EngineModel
QSL8.9-C325
Power rating242/2100 kW/rpm
Fuel tank volume590 L
-
Feed systemTotal length
7300 mm
Feed extension1200 mm
Pitch angle140 °
Turning angle-20~90 °
Feed force30 kN
-
Drill boomType
Folding boom
Lifting angle70~-10 °
Folding angle65~165 °
Swing angle20~-30 °
-
DimensionWeight
16500 kg
LxWxH（ Work ）9.5× 2.6× 8.6 m
LxWxH（ Transportation ）12× 2.6× 3.5 m
