ZA26J DIESEL ARTICULATING BOOM LIFT
-
Large work range, max work height of 28.2m, max outreach of19.4m, and up and over height of 9.48m
-
Build-in multiple pressure control leveling system to enhance stability
-
Precise load sensing system to improve overload safety operations
-
Pump control +valve control for accurate flow distribution
-
Outstanding below ground reach of 6.5m (16ft 9in)
-
Jib, main boom and tower boom limit position buffer for comfort operation
-
Platform fast lifting function provides high-efficient performance without tower boom operation
-
Small stowed size, able to access container for transportation for lower transporting cost
| Work Height | 28.2m |
| Platform Height | 26.2m |
| Horizontal Outreach | 19.4m |
| Up and Over Height | 9.48m |
| A - Stowed Length | 11.75m |
| B - Stowed Width | 2.49m |
| C - Stowed Height | 2.82m |
| D - Platform Length | 2.44m |
| E - Platform Width | 0.91m |
| F - Wheelbase | 3.05m |
| G - Ground Clearance | 0.42m |
| Platform Capacity | 250kg |
| Drive Speed | 5.0km/h |
| Gradeability | 45%(24°) |
| Axles Oscillation | 0.2m |
| Turning Radius (Inside) | 3.14m |
| Turning Radius (Outside) | 6.48m |
| Turntable Swing | 360° continuous |
| Platform Rotation | ±90° |
| H-Tail Swing | 1.422m |
| Max. Working Slope | 5° |
| Max. Wind Speed | 12.5m/s |
| Diesel Engine | Kubota V2607/KubotaV3307 |
| Fuel Tank Capacity | 150L |
| Auxiliary Power | 12V |
| Control Voltage | 12V |
| Hydraulic System Capacity | 263L |
| Hydraulic Tank Capacity | 180L |
| Type | Foam-filled Tires |
| Gross | 18800kg |
