ZX37T SPIDER LIFT
-
1.2m ultra-narrow width,quick-change work platform, easy access to compact spaces
-
120kg/230kg/330kg various loads for various working conditions
-
Engine+Plug-in work mode for multiple applications
-
Symmetric layout boom, great structural rigidity, and small boom deflection
-
Telescopic jib for flexible boom end
-
Non-marking rubber track suitable for all terrains
| Work Height | 37m |
| Platform Height | 35m |
| Horizontal Outreach | 15.7m |
| Up and Over Height | / |
| Below Ground Reach | 5.7m |
| A - Stowed Length (w/ platform） | 7.9m |
| D - Stowed Length (w/o platform) | 7.9m |
| B - Stowed Width | 1.2m |
| C - Stowed Height | 1.99m |
| E - Platform Length | 1.8m |
| F - Platform Width | 0.7m |
| G - Platform Height | 1.1m |
| H - Crawler Size (Length×Width) | 2.43m x 0.3m |
| I - Max Length w/ Outrigger Extending (Standard) | 5.55m |
| J - Max Width w/ Outrigger Extending (Standard) | 2.68m |
| K - Max Length w/ Outrigger Extending (Narrow) | 7.35m |
| L - Max Width w/ Outrigger Extending (Narrow) | 5.4m |
| Outrigger Pad Size (Diameter) | / |
| Approach Angle | / |
| Depature Angle | 24° |
| Platform Capacity | 230kg/330kg（restricted）/120kg（unrestricted） |
| Drive Speed | 2km/h |
| Gradeability | 19.8°/36% |
| Allowable Tilting Angle When Driving | 8.5/15% |
| Turntable Swing | 360°continuous |
| Platform Rotation | ±90° |
| H-Tail Swing | 0m |
| Max Leveling Angle | 13° |
| Max Wind Speed | 12.5m/s |
| Battery | / |
| Charger | / |
| Drive Motor | / |
| Lift Motor | / |
| Auxiliary Power | Electric pump |
| Hydraulic Tank Capacity | 110L |
| Tire | / |
| Crawler type | Non-marking rubber track |
| Gross weight | 8400kg |
| Ground Pressure When Driving | 36.9N/㎡ |
| Ground Pressure When Working (Standard) | 2.80N/㎡ |
| Ground Pressure When Working (Narrow) | 4.26N/㎡ |
| Pressure on Single Outrigger When Working | 47KN |
