SWE17F

Technical Parameters

• Basic Parameter
  Operating Weight

  1780 kg

  Bucket Capacity

  0.035 m³

• Overall Dimension
  Overall Length

  3840 mm

  Overall Height

  2360 mm

  Overall Width

  990 mm

  Counterweight Clearance

  460 mm

  Ground Clearance

  160 mm

  Tail Swing Radius

  1110 mm

  Length to Center of Rollers

  1210 mm

  Track Length

  1555 mm

  Track Gauge

  760/1130 mm

  Track Width

  990/1360 mm

  Track Shoe Width

  230 mm

  Max. Height of Cab

  2360 mm

  Uppercarriage Width

  990 mm

• Working Range
  Boom Length

  1800 mm

  Arm Length

  950 mm

  Max. Digging Height

  3535 mm

  Max. Dumping Height

  2440 mm

  Max. Digging Depth

  2060 mm

  Max. Depth Cut for 2440 mm Level Bottom

  1395 mm

  Max. Vertical Digging Depth

  1760 mm

  Max. Digging Reach

  3885 mm

  Max. Digging Reach at Ground Level

  3765 mm

  Min. Front Swing Radius

  1580 mm

  Max. Raising Height above Ground of Dozer Blade

  240 mm

  Max. Lowering Depth from Ground of Dozer Blade

  240 mm

• Performance
  Bucket Digging Force

  21 kN

  Arm Digging Force

  12 kN

  Max. Drawbar Pull

  18.5 kg

  Gradeability

  57 %

  Ground Pressure

  30 kPa

  Travel Speed(Max/Min)

  4.5/2.5 km/h

  Swing Speed

  10 rpm

• Oil Tank Capacity
  Fuel Tank Capacity

  21 L

  Hydraulic Tank Capacity

  26 L

• Engine
  Model

  3TNV80-SSU Stage Ⅴ

  Rated Power

  13.4/2200 kw/rpm

  Max. Torque

  67.4/1600 N.m/rpm

  Displacement

  1.267 L

• Hydraulic System
  Main pump
  Type

  One variable plunger pump

  Max.Flow

  62 L/min

  System Pressure

  24.5 MPa

  Pilot pump

  Type

  –

  Max.Flow

  – L/min

  Pressure

  3.5 MPa

  Flow of Aux 1（break）

  45 L/min

  Flow of Aux 2

  45 MPa
