ZMP06 VERTICAL MAST LIFT
-
Permanent magnet synchronous traveling motor, energy saving and highefficiency
-
Standard large-diameter tires and collectable pothole plates, easy topass the threshold
-
Front wheel driving and steering and small turning radius for flexibleindoor movement
-
Multi-arm synchronous lifting,fast and no impact
-
Compact dimensions, access to lifts, and ideal for indoor application5
| Work height | 7.91m |
| A - Platform Height-Elevated | 5.91m |
| B - Platform Height-Stowed | 0.6m |
| C - Platform Length | 1.02m |
| D - Platform Width | 0.76m |
| K-Platform Extension | 0.5m |
| E - Overall Height | 1.99m |
| F - Overall Length | 1.39m |
| G - Overall Width | 0.78m |
| H - Wheelbase | 1.06m |
| I - Ground Clearance (Stowed) | 0.065m |
| J - Ground Clearance (Raised) | 0.017m |
| Platform Capacity | 200kg |
| Capacity on Deck Extension | 113kg |
| Max. Number of Workers(indoor/outdoor) | 1/0 |
| Drive Speed (Stowed) | 4km/h |
| Drive Speed (Raised) | 0.5km/h |
| Turning Radius (Inside) | 0.14m |
| Turning Radius (Outside) | 1.43m |
| Lifting Motor | 24V/2.5KW |
| Drive Motor | 24V/2×0.6KW |
| Up/Down Time | 25/30s |
| Gradeability | 25%（14°） |
| Max. Working Slope(Lateral/Vertical) | 1.5°/3° |
| Control | Proportional control |
| Drive | Front wheels |
| Brake | Front wheels |
| Tire | Solid seamless tire |
| Battery | 2×12V/137Ah |
| Charger | 24V/20A |
| Gross | 1100kg |
相关产品
-
ELECTRIC ROUGH TERRAIN ARTICULATING BOOM LIFTS
