ZA42J DIESEL ARTICULATING BOOM LIFT
-
Provide heavy lifting of 275kg/454kg load
-
Multi-way valve control, pressure compensation function, smooth and accurate control
-
Precise load sensing system to improve overload safety operations
-
Deadweight Lowering System for smooth operation and energy efficiency
-
Outstanding below ground reach of 5.5m
-
X-outrigger for larger work range and better stability
| Work Height | 44.03m |
| Platform Height | 42.03m |
| Horizontal Outreach | 21.9m |
| Up and Over Height | 24.5m |
| A - Stowed Length | 12.6m |
| B - Stowed Width | 2.49m |
| C - Stowed Height | 3.1m |
| D - Platform Length | 2.44m |
| E - Platform Width | 0.91m |
| F - Wheelbase | 4.1m |
| G - Ground Clearance | 0.42m |
| Platform Capacity | 275kg/454kg |
| Drive Speed | 5.2km/h |
| Gradeability | 45% |
| Axles Oscillation | 0 |
| Turning Radius (Inside) | / |
| Turning Radius (Outside) | 9.5/6.7m |
| Turntable Swing | 360° continuous |
| Platform Rotation | ±90° |
| H-Tail Swing | 0.8m |
| Max. Working Slope | 5° |
| Max. Wind Speed | 12.5m/s |
| Diesel Engine | Kubota V2607 |
| Engine Power | / |
| Fuel Tank Capacity | 200L |
| Auxiliary Power | 12V |
| Control Voltage | 12V |
| Hydraulic System Capacity | 350L |
| Hydraulic Tank Capacity | 250L |
| Type | 445/50D710 Foam-filled Tires |
| Gross | 23200kg |
